- The labeling height and angle are adjustable.
- Horizontal wrap station is designed for cylinder containers that can't stand vertically.
- Equipped with a pharmaceutical conveyor belt to eliminate friction.
- Conveyor belt and labeling speed are adjustable.
- Controlled by a Microprocessor system with an LED screen.
- No repositioning or timing adjustment is necessary when changing bottle size.
- An advanced detection system makes precise labeling.
- No bottle, no labeling.
- Labeling speed is synchronized with the conveyor belt.
- Emergency stop button
- All are made of stainless steel and high-quality aluminum alloy.
Features
Specifications
- Labeling speed: 80~150 pcs/ min (depends on containers and label size)
- Bottle size: diameter 9.5 mm- 25 mm/ height 30-160 mm
- Label size: (W) 10~100mm / (L) 20~300mm
- Label reel: Inner diameter 75mm / Outer Diameter 300mm
- Accuracy: ± 1mm
- Supply power: 110V or 220VAC, 50/60Hz
Option Accessories
- Transparent label sensor
- Date coder
- Automatic feeding turntable
- PLC system, touch screen.
- Mitsubishi servo motor
- Stainless cabin
Description
Description
Horizontal round bottle labeler LR4600 is suitable for cylindrical containers and products that can’t stand stably, such as ampoules, crayons, lip balms, etc.
