Specifications


Power Supply 1 Phase 110V/220V/240V
Packing Size Max: L x W500 x H500 mm Min: L150 x W135 x H120mm
Tape Width 50 mm (2”) or 76 mm (3”)
Working Table Height 570-770mm (Adjustable)
Transmit Speed 20M / Mn
Dimensions L1240 x W910 x H1320
Air Compressor 6 kg / cm2
Net Weight 165 kg


Description

Fully Automatic Top and Side Double Belts Driving Carton Sealing Machine CXF3

  • To adjust the height and width in accordance with the different sizes of cartons automatically.
  • The side driving device can automatically fix the position of the carton, start sealing, and the whole operation is stable.
  • Fully Automatic Top and Side Double Belts Driving Carton Sealing Machine CXF3 has top and side driving belts that are suitable for heavy products.
  • The side motors and upper taping head are controlled by the cylinder and automatically fix the position of the carton. It is available as an automatic packing system.
  • The table height can be adjusted according to the height of the input & output conveyors

Specifications

Power Supply

1 Phase 110V/220V/240V

Packing Size

Max: L x W500 x H500 mm

Min: L150 x W135 x H120mm

Tape Width

50 mm (2”) or 76 mm (3”)

Working Table Height

570-770mm (Adjustable)

Transmit Speed

20M / Mn

Dimensions

L1240 x W910 x H1320

Air Compressor

6 kg / cm2

Net Weight

165 kg
