Automatic Bottle Rinsing Filling and Capping Machine

Description

Automatic Bottle Rinsing Filling and Capping Machine

This is a touchscreen PLC-based Rotary Automatic Bottle Rinsing Filling and Capping Machine. This machine is mainly used for bottle rinsing, filling, and capping of drinks such as Beverages, Soft drinks, Juice, Synthetic Flavoured Juice, etc.

The Automatic Bottle Rinsing Filling and Capping Machine design shortens the time for the packaging, reduces outside contamination, increases the sanitation condition throughout the machine, and is economical. Neostarpack is a filling capping machine manufacturer, supplier, and service provider of food and beverage processing plants and machines in Taiwan.

Packaging Segment:

1. Automatic Bottle Rinsing Filling and Capping Machine
2. Jar Filling Machine

3. Juice Filling Machine



Advantages:

1. Fully automatic in-line system from rinsing, filling to capping.

2. Flexible to fill various liquids from water-thin to heavy paste products in a variety of bottle materials, sizes, and filling volumes.

3. Applied to a wide range of industries including cosmetics, chemicals, pharmaceuticals, food, and beverages.

Features

1. Comprehensive and complete bottle filling solution.

2. Any packaging stations can be customized to meet your sourcing need.

3. Automatic Bottle Rinsing Filling and Capping Machine’s efficient design enables quick change-over for different product.

4. Automatic Bottle Rinsing Filling and Capping Machine is built with anti-dust housing, hygiene concerning.

5. Automatic Bottle Rinsing Filling and Capping Machine has two rinsing options, water and vacuum.

6. Automatic Bottle Rinsing Filling and Capping Machine has a bottle turnover device.

7. Automatic Bottle Rinsing Filling and Capping Machine’s filling nozzles can be customized to meet the specialty

8. Automatic Bottle Rinsing Filling and Capping Machine’s advanced valves prevent liquid from dripping down.

9. Drip tray setting, surplus liquid backflow, no waste.

10. High torque design for quality capping.

11. Cap elevator, feeding cap automatically and smoothly.

12. Automatic Bottle Rinsing Filling and Capping Machine adopts a precise sensor, smart operating, no bottle, no rinsing, no filling, and no capping.

13. Colorful touch screen controller.The

14. Automatic Bottle Rinsing Filling and Capping Machine has a user-friendly PLC+HMI system.

15. Automatic Bottle Rinsing Filling and Capping Machine is equipped with alarms that control production conditions immediately.

16. Job memory device, quick and simple changeover.

17. Front panel Start and Emergency Stop button.

18. Multiple rinsing, filling, feeding and capping speeds for accurate control of production.

19. Automatic Bottle Rinsing Filling and Capping Machine has automatic pneumatic gates for bottle entry and exit

20. Automatic Bottle Rinsing Filling and Capping Machine has a sturdy conveyor.

21. Conveyor guide rail can be adjusted to accommodate any size of bottles

22. Mounted casters, easy to move.

23. Robustness construction, easy maintenance, and longevity.

24. Automatic Bottle Rinsing Filling and Capping Machine’s stainless Steel enclosure provided for complete hygienic bottling.

25. Unique pick and place type capping with adjustable torque mechanism.

26. Speed Control by AC Drive.

27. Easy-open nozzles for easy cleaning.

Specification

RINSING MACHINE

• Rinsing way： Water and Vacuum
• Rinsing speed： Max. 30bpm
• Machine dimension：(L) 5100mm(W) 1500mm(H) 2400mm
• Machine weight：400 KG
• Power supply：110/220VAC, 50/60HZ, 1 PHASE

FILLING MACHINE

• Speciality products：■Foamy ■Corrosive ■Warm ■Particulate
• Filling speed：Max. 250ml/sec
• Filling range：Max. 5000ml
• Filling accuracy：± 0.5%
• Machine dimension：(L) 5100mm(W) 1500mm(H) 2400mm
• Machine weight：500 KG
• Power supply：110/220 VAC, 50/60HZ, 1 PHASE
• Air pressure requirement：90PSI/3CFM

CAPPING MACHINE

• Speciality products：■Screw cap ■ROPP cap
• Cap diameter： Max. 30mm
• Capping speed： Max. 30bpm
• Machine dimension：(L) 2000mm(W) 1200mm(H) 1600mm
• Machine weight：350 KG
• Power supply：110/220VAC, 50/60HZ, 1 PHASE
• Air pressure requirement：90PSI/3CFM
